Features:

■ A radial glass-encapsulated thermistor element is sealed with epoxy resin
■ Proven long term Stability , Reliability, and high Durability
■ High Sensitivity and the Fastest thermal response
■ PVC cable,XLPE insulated wire

Applications:

■ Mainly used for Car Air Conditioning, Evaporators
■ Home appliances: air conditioner, refrigerator, freezer, air heater, dishwasher, etc.
■ Water heaters, heat pump water heaters and coffee makers (water)
■ Bidets (instant inlet water)

Characteristics:

1. Recommendation as follows:
R25℃=10KΩ±1% B25/50℃=3950K±1% or
R25℃=15KΩ±3% B25/50℃=4150K±1% or
R25℃=100KΩ±1%, B25/50℃=3950K±1%
2. Working temperature range: -40℃～+105℃
3. Thermal time constant: MAX.10sec.
4. Insulation voltage: 1500VAC,2sec.
5. Insulation resistance: 500VDC ≥100MΩ
6. Teflon cable or XLPE cable is recommended
7. Connectors are recommended for PH, XH, SM, 5264 and so on
8. Above characteristics all can be customized

Product specification:
