Surface Mount Temperature Sensor for Automobile battery charger,Heatsinks,Printer and Copy Machine

This temperature sensor was originally applied to the heatsink, copy machine and multi-function printer, and later was also applied to the charger of the car battery, the insulation performance is good, and the built-in components can be glass thermistor or bare chip two ways, this results in a slight difference in their thermal response time and sealing performance, and a slight difference in price.
MFS Series temperature sensor, easy to install and fixed to the surface of measured subject by screw, which is widely used to detect the surface temperature for Electric Vehicle Battery Management Systems,OA Equipments, Battery Cooling Systems, UPS power cooling fan, OBC Charger, heating plate of coffee machine, bottom of coffee pot, ovenware and so on. They can meet the requirements of measuring temperature and overheating protection which for a better protection of machine.

Features:

■ A glass-encapsulated thermistor or bare chip is sealed into a lug terminal, Easy to install, size can be customized
■ Proven long term Stability and Reliability, Excellent performance of voltage resistance
■ High Sensitivity and Fast thermal response, Moisture and high temperature resistance
■ Surface mountable and various mounting options
■ Usage of Food-grade level SS304 housing, meet the FDA and LFGB certification
■ Products are in accordance with the RoHS, REACH certification

Applications:

■ OA Equipment, Heatsinks, EV Battery Management Systems
■ Automobile inverters, Heat pump water heaters (surface)
■ Coffee machine, Heating plate, Ovenware
■ Air-conditioners outdoor units and heatsinks (surface)
■ Automobile battery chargers, evaporators, Battery Cooling Systems
■ Water heater tanks and OBC Charger, BTMS,

Characteristics:

1. Recommendation as follows:
R25℃=10KΩ±1% B25/50℃=3950K±1% or
R25℃=15KΩ±3% B25/50℃=4150K±1% or
R25℃=100KΩ±1%, B25/50℃=3950K±1%
2. Working temperature range:
-30℃～+105℃ or
-30℃～+150℃
3. Thermal time constant: MAX.15sec.( typical in stirred water )
4. Insulation voltage: 1800VAC,2sec.
5. Insulation resistance: 500VDC ≥100MΩ
6. PVC, XLPE or teflon cable is recommended
7. Connectors are recommended for PH, XH, SM, 5264 and so on
8. Above characteristics all can be customized
